Satin Stainless Steel Semi-Frameless Glass Balustrade Kit – Low Level

Key Features

  • 42.4mm round posts, 1100mm high, 316 marine-grade stainless steel, brushed satin
  • 10mm toughened glass in 5 colours: stock sizes or cut to size
  • Low-level use: drops under 600mm
  • Matching satin glass gate kit
  • CAD drawing for approval before any glass is cut
SKU: SF-KIT-S
Availability: Many In Stock
Glass balustrade calculator — Satin

Tell us your measurements and we’ll work out your posts, caps and glass, then add it all to your basket in one click. 316 marine-grade stainless steel posts with a brushed satin finish, with 10mm toughened glass — stock sizes wherever your run allows.

Two sections side by side, each made of Run 1, Run 2 and Run 3 joined at right-angle corners, where Run 3 goes down the stairs. How sections and runs fit together Two sections, each made of three runs Section 1 Section 2 Run 1 Run 2 Run 3 (stairs) Run 1 Run 2 Run 3 (stairs) Reading the diagram Dots are posts — each junction shares one. Lines are runs. Run 3 here goes down stairs.
Side view of stairs with the run measured along the rake, post to post. Measuring a stair run Measure along the slope, post to post post post measure along here Measure on the angle of the slope to where you plan to have your posts mounted at the top and bottom of your stairs.
Measurement unit
Gates
A complete kit — self-closing hinges, latch, pre-drilled glass pane and fixings.
The glass gate kit is a self-contained unit that hangs between two posts: two self-closing hinges, a latch, a pre-drilled 10mm toughened glass pane (1024mm height for this system) and its fixings. If your gate sits in the middle of a stretch, enter the runs either side of the gate as separate sections — the gate hangs between the two end posts. We’ll confirm your exact gate layout with CAD drawings after you order.
0
Get a Free Quote

Measure each run outside-to-outside (the full length of the edge you want the balustrade to cover), in your chosen unit, and the calculator works out your posts, caps and glass with posts spaced evenly at a maximum of 1200 mm centres. We fit your runs to stock pane sizes wherever they will go, so most orders are dispatched in around 7 working days. Anything that cannot be made from stock is cut to size for your exact space: it’s charged by the linear metre of run, with your job total rounded up to the next whole metre, and before anything is cut we send you CAD drawings to confirm every measurement and pane size. Made-to-order glass takes 3–4 weeks and is non-returnable unless faulty. Inside a section, runs join at a shared post — a corner junction uses a corner post and a straight junction (for example a flat run continuing into a stair run) uses a mid post. Stair runs use the same posts and clamps as level runs; the stair glass is confirmed on your CAD drawings. Ground fixings and post caps: fixings aren’t included (the right anchor depends on your surface), and one post cap per post is added automatically.

Secure checkout — pay your way

Visa Mastercard PayPal Apple Pay Google Pay
  • The Outdoor Look
  • The Outdoor Look
  • The Outdoor Look
  • The Outdoor Look
Delivery: £60 to most UK mainland — free on orders over £2,000. Delivered within 3-4 weeks; exact cost confirmed at checkout by postcode.
Full delivery & returns details →
Fully Compliant to British Building Regulations
Designed in line with BS 6180:2011
