Satin Stainless Steel Spigot Glass Balustrade Kit

Key Features

  • Square Duplex 2205 stainless spigots — satin finish, frameless look with no posts or channel
  • Glass chosen by drop — 10mm toughened under 600mm; 17.5mm laminated at 600mm or more
  • Two spigots per panel — fixed 150mm in from each edge, no more than 700mm apart
  • Optional top rail — added along the whole run where there are stairs
  • Designed in line with BS 6180:2011 — for homes, at drops of 600mm or more
SKU: SPIG-BYO-S
Availability: Many In Stock
Spigot glass balustrade calculator — Satin

Tell us your measurements and we’ll work out your glass, spigots and fittings, then add it all to your basket in one click. Square spigots in brushed Duplex 2205 stainless steel, holding toughened glass panels with no posts and no base channel.

A section made of three runs joined at corners, with glass panels standing on pairs of spigots. How sections and runs fit together One section, three runs, panels on paired spigots Run 1 Run 2 Run 3 Reading the diagram Small marks are spigots — two under every panel. Lines are runs. There are no posts in this system.
Plan view showing a run measured outside to outside along the edge. Measuring a run Measure the full edge you want covered measure the whole edge Glass sits just inside the edge so every base plate lands on solid ground. The calculator allows for that automatically.
1. How big is the drop?

Measure from the finished floor down to the ground below. This is what decides your glass.

Measurement unit
2. Do you want a top rail?
Satin anodised aluminium top rail, 30 x 28mm U-profile

The rail in the picture is a slotted aluminium cap that sits over the top edge of the glass. It gives you something to hold, ties the panels together and finishes the run. Optional — the glass stands on its own without it.

Need help? Send us your sizes

Measure each run outside-to-outside (the full length of the edge you want the balustrade to cover), in your chosen unit, and the calculator works out your glass, spigots and fittings. There are no posts in this system: each toughened glass panel stands on a pair of floor-fixed spigots, with a narrow joint between panels. Under a 600 mm drop, panels are 10 mm toughened glass up to 1100 mm wide and 1024 mm high. At 600 mm or more, panels are 17.5 mm laminated glass up to 1000 mm wide and 1087 mm high, with the spigots 150 mm in from each panel edge so they are never more than 700 mm apart. We fit your runs to stock pane sizes wherever they will go, so most orders are dispatched in 3–10 working days; anything that cannot be made from stock is cut to size, charged by the linear metre and rounded up to the next whole metre, and before anything is cut we send you CAD drawings to confirm every measurement and pane size. Made-to-order glass takes 3–4 weeks and is non-returnable unless faulty. Stair runs are always cut to size, because a raked panel is shaped to the pitch of your particular flight. Spigots must be bolted into a solid structural base — concrete, a steel frame or a retaining wall, not paving laid on sand. Fixing bolts are not included, as the right anchor depends on what you are fixing into. One base plate cover is included per spigot.

Secure checkout — pay your way

Visa Mastercard PayPal Apple Pay Google Pay
  • The Outdoor Look
  • The Outdoor Look
  • The Outdoor Look
  • The Outdoor Look
Delivery: £60 to most of mainland UK — free on orders over £2,000. Stock glass is dispatched in 3–10 working days; made-to-measure glass takes 3–4 weeks. Exact cost confirmed at checkout by postcode.
Full delivery & returns details →
Built for UK homes
Designed in line with BS 6180:2011
